Description
Vertical Cable 062 Series Category-6 shielded (F/UTP) riser-rated (CMR) cable in White, 1000 ft. The overall foil shield helps protect against EMI/RFI in electrically noisy environments while supporting Gigabit Ethernet and PoE.
Constructed with 4 pairs (8 conductors) of 23 AWG solid bare copper with PE insulation and a PE cross filler, wrapped in PET tape with an AL/PET foil shield and tinned-copper drain wire, inside a PVC jacket with a 0.28 in. (7.2 mm) diameter and rip cord. Rated to 550 MHz, 100 ohm impedance, 70% NVP.
ETL Listed and RoHS compliant. Meets or exceeds ANSI/TIA-568.2-D and ISO/IEC 11801 transmission performance specifications. Supports PoE Type 3 (IEEE 802.3bt). Riser fire safety rating (CMR, FT4). Compatible with Vertical Cable RJ45 plugs 012-021-100 and 012-026/EZF-100.
- Overall Foil-Shielded Twisted-Pair (F/UTP) construction
- Riser Fire Safety Rating (CMR)
- 23 AWG solid bare copper conductors
- 550 MHz
- Easy-to-see vivid-color conductor insulation & jacket
- Supports PoE Type 3 IEEE 802.3bt
- ETL Listed, RoHS compliant
- Designed in the USA, imported product
- 1000 ft.
